Diamond MICRO85U

Diamond Audio continues to push boundaries with the introduction of the MICRO8U series amplifiers for 2018. Building on the success of the popular MICRO series, the big-brother MICRO8U series amplifiers deliver even more power and performance, setting a new standard in audio excellence.

Engineered from the ground up, these amplifiers not only provide increased power but are also conformal-coated for all-weather applications and outdoor environments. This makes them perfect for a wide range of installations, ensuring durability and reliability no matter the conditions.

Experience the next level of power, performance, and design with the MICRO8U series amplifiers from Diamond Audio. Upgrade your audio system today and enjoy unparalleled sound quality and durability, whether you’re indoors or out.

Product Details:

• Micro8U Series Class D 2 ohm Stable 5-Channel Amplifier
• RMS Power Rating:
  • 4 ohm: +
  • 2 ohm: 85 watts x 1 channel + 375 watts x 1 channel
  • Bridged: 200 watts x 1 channel @ 4 ohm + 375 watts x 1 channel @ 2 ohm
• Total RMS power output: 1035 watts
• LED Power/Protect Light
• Speaker-level (high-level) inputs
• 3-way protection circuitry (thermal, overload, and speaker short protection)
• DirectFET Power MOSFET output stage
• SMD technology on 4-layer glass PC board
• Conformal coated PCB assembly for added water resistance
• ICAD circuit provides superior overload protection
• Variable 12dB crossovers
• Input sensitivity: 200 mV – 10 volts
• Frequency Response: 10 – 30000 Hz
• Total Harmonic Distortion (THD): 0.5%
• Signal to Noise Ratio: -85 dB
• Variable high-pass filter: 40 – 400 Hz
• Variable low-pass filter: 40 – 400 Hz
• Variable Bass Boost: 0 – 12 dB
• Fuse Rating: 60A
• 8 AWG gauge amplifier wiring kit is recommended for installation
• Dimensions: 10.45″ L x 4.02″ W x 1.4″ H
