Limitless Lithium ES1250-3W12D2

Here is the detailed product breakdown for the 12″ 1250-Watt Dual 2-Ohm Bagger Subwoofer, professionally structured for your Listinglo e-commerce catalog.

12″ Elite Series Bagger Subwoofer | 1250W Peak / 625W RMS

Configuration: Dual 2-Ohm Voice Coils

Application: High-Output Saddlebag Bass / Custom Bagger Enclosures

This 12-inch Bagger Subwoofer is designed for the rider who demands maximum power efficiency. By utilizing Dual 2-Ohm Voice Coils, this driver allows you to wire a single sub into a 1-Ohm load or 4-Ohm load, providing the perfect match for high-current monoblock amplifiers. Specifically tuned for the acoustic volume of a motorcycle saddlebag, this “long-throw” woofer delivers the low-frequency extension (sub-bass) that typically disappears once you hit cruising speeds.

Detailed Technical Specifications

1. High-Current Motor Architecture

• Power Handling: 625 Watts RMS | 1250 Watts PEAK.

• Voice Coil: 2.5″ (63.5mm) Black Aluminum Former with high-temp OFC (Oxygen Free Copper) windings.

• Magnet Assembly: Massive 140oz High-Flux Double-Stacked Ferrite Motor with a CNC-machined back plate.

• Impedance: Dual 2-Ohm (Configurable to 1-Ohm or 4-Ohm).

2. Weatherproof “Open-Air” Design

• Cone Material: Kevlar® Reinforced Non-Pressed Paper with a hydrophobic (water-repellent) coating for all-weather durability.

• Surround: Oversized, High-Excursion ($X_{max}$) EPDM Rubber Surround, UV-treated to prevent cracking in direct sunlight.

• Spider: Mirrored Progressive Nomex Spiders to maintain cone linearity during extreme excursion.

• Cooling: Integrated Aero-Vent pole piece and perimeter basket venting to dissipate heat during extended “parking lot” sessions.

3. Performance Parameters

• Sensitivity: 89.2 dB (1W/1m).

• Frequency Response: 25Hz – 450Hz.

• Mounting Depth: 6.15″ (156mm).

• Cutout Diameter: 11.12″ (282mm).
